Brocade TurboIron 24X Series Configuration Guide

789

53-1003053-01

PIM SM snooping show commands

Syntax: show ip multicast pimsm-snooping vlan

Enter the ID of the VLAN for the vlan parameter.

If you want to display PIM SM snooping information for one source or one group, enter a command
as in the following example. The command also displays the (source, port) list of the group.

Syntax: show ip multicast pimsm-snooping |

If the address you entered is within the range of source addresses, then the router treats it as the
>. Likewise, if the address falls in the range of group addresses, then the router
assumes that you are requesting a report for that group.

This display shows the following information.

Displaying PIM SM snooping information for a specific
group or source group pair

To display PIM SM snooping information for a specific group, enter a command such as the
following at any level of the CLI.

TABLE 116

This field...

Displays...

VLAN ID

The port-based VLAN to which the information listed below apply and the number of
members in the VLAN.

PIM SM Neighbor list The PIM SM routers that are attached to the Layer 2 Switch ports.

The value following “expires” indicates how many seconds the Layer 2 Switch will wait for a
hello message from the neighbor before determining that the neighbor is no longer present
and removing the neighbor from the list.

Multicast Group

The IP address of the multicast group.
NOTE: The fid and camindex values are used by Brocade Technical Support for

troubleshooting.

Forwarding Port

The ports attached to the group receivers. A port is listed here when it receives a join
message for the group, an IGMP membership report for the group, or both.

PIMv2 Group Port

The ports on which the Layer 2 Switch has received PIM SM join messages for the group.

Source, Port list

The IP address of each PIM SM source and the Layer 2 Switch ports connected to the
receivers of the source.

TurboIron#show ip multicast pimsm-snooping 239.255.163.2

Show pimsm snooping group 239.255.163.2 in all vlan

VLAN ID 100

Group: 239.255.163.2, fid 08a9, cam 10

Forwarding Port: 1 2

PIMv2 Group Port: 1 2

(Source, Port) list: 3 entries

1 10.168.176.44, age=0, port: 2

2 10.158.158.158, age=0, port: 1

3 10.1.7.1, age=0, port: 2
