Dynamic link aggregation
shows examples of the ports from
that will be eligible for an aggregate link
based on individual port states.
As shown in these examples, all or a subset of the ports within a port range will be eligible for
formation into an aggregate link based on port states. Notice that the sets of ports that are eligible
for the aggregate link must be valid static trunk configurations.
Enabling dynamic link aggregation
By default, link aggregation is disabled on all ports. To enable link aggregation on a set of ports,
enter commands such as the following at the Interface configuration level of the CLI.
NOTE
Configuration commands for link aggregation differ depending on whether you are using the default
link aggregation key automatically assigned by the software, or if you are assigning a different,
unique key. Follow the commands below, according to the type of key you are using. For more
information about keys, refer to
TABLE 63
Port eligibility for link aggregation
Port group 1
Port group 2
Trunk eligibility
1
2
3
4
Link State Up
Up
Up
Up
4-port
1 – 4
Up
Up
Up
Down
4-port
1 – 4
Up
Down
Up
Down
4-port
1 – 4
Up
Up
Down
Up
4-port
1 – 4
Down
Down
Down
Up
2-port
3 – 4
Up
Down
Down
Down
2-port
1 – 2
Port1
Port2
Port3
Port4
Group 1
Group 2
