PIM Sparse
Displaying the PIM multicast cache
To display the PIM multicast cache, enter the following command at any CLI level.
TurboIron#show ip pim mcache
(* 228.1.0.88) RP 10.1.1.1, in e21 (e21), cnt=0
Source is directly connected
Sparse Mode, RPT=1 SPT=0 REG=0 MSDP Adv=0 MSDP Create=0
L3 (SW) 3: e2(VL33), e1(VL5), TR(e13,e14)(VL55)
fast=1 slow=0 pru=1 graft
age=0s up-time=4123m HW=0
Syntax: show ip pim mcache
This display shows the following information.
TABLE 126 Output of show ip pim flowcach commande
This field... Displays...
Source Indicates the source of the PIM Sparse group.
Group Indicates the PIM Sparse group.
Parent Indicates the port or virtual interface from which the Layer 3 Switch receives packets from the
group source.
CamFlags This field is used by Brocade technical support for troubleshooting.
CamIndex This field is used by Brocade technical support for troubleshooting.
Fid This field is used by Brocade technical support for troubleshooting.
Flags This field is used by Brocade technical support for troubleshooting.
TABLE 127 Output of show ip pim mcache command
This field... Displays...
(source, group) The comma-separated values in parentheses is a source-group pair.
The source is the PIM source for the multicast group. For example, the following entry
means source 10.157.24.162 for group 239.255.162.1: (10.157.24.162,239.255.162.1)
If the source value is * (asterisk), this cache entry uses the RP path. The * value means
“all sources”.
If the source is a specific source address, this cache entry uses the SPT path.
RP Indicates the RP for the group for this cache entry.
NOTE: The RP address appears only if the RPT flag is set to 1 and the SPT flag is set to 0
(see below).
forward port The port through which the Layer 3 Switch reaches the source.
Count The number of packets forwarded using this cache entry.
Sparse Mode Indicates whether the cache entry is for regular PIM (dense mode) or PIM Sparse. This flag
can have one of the following values:
•
0 – The entry is not for PIM Sparse (and is therefore for the dense mode of PIM).
•
1– The entry is for PIM Sparse.
