Determining the software versions installed and running on a device
NOTE
If you are attempting to transfer a file using TFTP but have received an error message, refer to
“Diagnostic error codes and remedies for TFTP transfers”
Determining the software versions installed and
running on a device
Use the following methods to display the software versions running on the device and the versions
installed in flash memory.
Determining the flash image version running on the device
To determine the flash image version running on a device, enter the show version command at any
level of the CLI. Some examples are shown below.
Compact devices
To determine the flash image version running on a Compact device, enter the show version
command at any level of the CLI. The following shows an example output.
The version information is shown in bold type in this example:
•
“07.2.02b071T203” indicates the flash code version number. The “T203” is used by Brocade
for record keeping.
•
“labeled as TIR07202b071” indicates the flash code image label. The label indicates the
image type and version and is especially useful if you change the image file name.
•
“Secondary TIR07202b071” indicates the flash code image file name that was loaded.
Determining the image versions installed in flash memory
Enter the show flash command to display the boot and flash images installed on the device.
TurboIron#show version
SW: Version 07.2.02b071T203 Copyright (c) 1996-2010 Brocade Communications
Systems, Inc.
Compiled on Dec 02 2010 at 08:07:06 labeled as TIR07202b071
(6092645 bytes) from Secondary TIR07202b071
Compressed Boot-Monitor Image size = 373767, Version:04.1.00T205 (grz04100)
HW: Stackable TurboIron-X24
==========================================================================
Serial #: XXXXXXXXXXX
P-ASIC 0: type B820, rev 01 subrev 00
==========================================================================
833 MHz Power PC processor 8541 (version 32/0020) 66 MHz bus
512 KB boot flash memory
31744 KB code flash memory
512 MB DRAM
The system uptime is 5 minutes 34 seconds
The system : started=warm start reloaded=by "reload"
