Displaying BGP4 information
Displaying information for a specific route
To display BGP4 network information by specifying an IP address within the network, enter a
command such as the following at any level of the CLI.
Syntax: show ip bgp [route] / [longer-prefixes] |
If you use the route option, the display for the information is different, as shown in the following
example.
These displays show the following information.
TABLE 110 BGP4 network information
This field... Displays...
Number of BGP Routes
matching display condition The number of routes that matched the display parameters you entered. This is
the number of routes displayed by the command.
Status codes A list of the characters the display uses to indicate the route status. The status
code appears in the left column of the display, to the left of each route. The
status codes are described in the command output.
NOTE: This field appears only if you do not enter the route option.
Prefix The network address and prefix.
Next Hop The next-hop router for reaching the network from the Layer 3 Switch.
Metric The value of the route MED attribute. If the route does not have a metric, this
field is blank.
LocPrf The degree of preference for this route relative to other routes in the local AS.
When the BGP4 algorithm compares routes on the basis of local preferences,
the route with the higher local preference is chosen. The preference can have a
value from 0 – 4294967295.
TurboIron#show ip bgp 10.3.4.0
Number of BGP Routes matching display condition : 1
Status codes: s suppressed, d damped, h history, * valid, > best, i internal
Origin codes: i - IGP, e - EGP, ? - incomplete
Network Next Hop Metric LocPrf Weight Path
*> 10.3.4.0/24 10.168.4.106 100 0 65001 4355 1 1221 ?
Last update to IP routing table: 0h11m38s, 1 path(s) installed:
Gateway Port
10.168.2.1 1
Route is advertised to 1 peers:
10.20.20.2(65300)
TurboIron#show ip bgp route 10.9.3.4
Number of BGP Routes matching display condition : 1
Status A:AGGREGATE B:BEST b:NOT-INSTALLED-BEST C:CONFED_EBGP D:DAMPED
E:EBGP H:HISTORY I:IBGP L:LOCAL M:MULTIPATH S:SUPPRESSED F:FILTERED
Prefix Next Hop Metric LocPrf Weight Status
1 10.9.3.4/24 10.168.4.106 100 0 BE
AS_PATH: 65001 4355 1 1221
Last update to IP routing table: 0h12m1s, 1 path(s) installed:
Gateway Port
10.168.2.1 1
Route is advertised to 1 peers:
10.20.20.20(65300)
