494

Brocade TurboIron 24X Series Configuration Guide

53-1003053-01

Displaying IP configuration information and statistics

bootp-relay-max-ho
ps

The maximum number of hops away a BootP server can be located from the router and still
be used by the router clients for network booting.
To change this value, refer to

“Changing the maximum number of hops to a BootP relay

server”

on page 484.

router-id

The 32-bit number that uniquely identifies the router.
By default, the router ID is the numerically lowest IP interface configured on the router. To
change the router ID, refer to

“Changing the router ID”

on page 455.

enabled

The IP-related protocols that are enabled on the router.

disabled

The IP-related protocols that are disabled on the router.

Static routes

Index

The row number of this entry in the IP route table.

IP Address

The IP address of the route destination.

Subnet Mask

The network mask for the IP address.

Next Hop Router

The IP address of the router interface to which the router sends packets for the route.

Metric

The cost of the route. Usually, the metric represents the number of hops to the destination.

Distance

The administrative distance of the route. The default administrative distance for static IP
routes in routers is 1.
To list the default administrative distances for all types of routes or to change the
administrative distance of a static route, refer to

“Changing administrative distances”

on

page 691.

Policies

Index

The policy number. This is the number you assigned the policy when you configured it.

Action

The action the router takes if a packet matches the comparison values in the policy. The
action can be one of the following:

deny – The router drops packets that match this policy.

permit – The router forwards packets that match this policy.

Source

The source IP address the policy matches.

Destination

The destination IP address the policy matches.

Protocol

The IP protocol the policy matches. The protocol can be one of the following:

ICMP

IGMP

IGRP

OSPF

TCP

UDP

Port

The Layer 4 TCP or UDP port the policy checks for in packets. The port can be displayed by
its number or, for port types the router recognizes, by the well-known name. For example,
TCP port 80 can be displayed as HTTP.
NOTE: This field applies only if the IP protocol is TCP or UDP.

Operator

The comparison operator for TCP or UDP port names or numbers.
NOTE: This field applies only if the IP protocol is TCP or UDP.

TABLE 75

CLI Display of global IP configuration information – Layer 3 Switch (Continued)

This field...

Displays...
