Classification
As shown in the figure, the first criteria considered is whether the packet matches on an ACL that
defines a priority. If this is not the case and the packet is tagged, the packet is classified with the
802.1p CoS value. If neither of these are true, the packet is next classified based on the static
MAC address, ingress port default priority, or the default priority of zero (0).
Packet received on
ingress port
Trust the DSCP-
CoS-mapping or
the DSCP-marking
Yes
No
Does the
packet match an
ACL that defines
a priority?
Does the
MAC address
match a static
entry?
Does the
port have a
default
priority?
Use the default
priority of 0
Trust the port’s
default priority
Trust the priority
of the static
MAC entry
Trust the 802.1p
CoS value
Yes
Yes
Yes
No
No
No
Is the packet
tagged?
Trust the
DSCP/ToS value
Yes
No
Does the
port have Trust
DSCP enable?
