Multicast Source Discovery Protocol (MSDP)
Notification Message Error
SubCode Transmitted See above.
TCP Statistics
TCP connection state The state of the connection with the neighbor. The connection can have one of
the following states:
•
LISTEN – Waiting for a connection request.
•
SYN-SENT – Waiting for a matching connection request after having sent
a connection request.
•
SYN-RECEIVED – Waiting for a confirming connection request
acknowledgment after having both received and sent a connection
request.
•
ESTABLISHED – Data can be sent and received over the connection. This
is the normal operational state of the connection.
•
FIN-WAIT-1 – Waiting for a connection termination request from the
remote TCP, or an acknowledgment of the connection termination request
previously sent.
•
FIN-WAIT-2 – Waiting for a connection termination request from the
remote TCP.
•
CLOSE-WAIT – Waiting for a connection termination request from the local
user.
•
CLOSING – Waiting for a connection termination request acknowledgment
from the remote TCP.
•
LAST-ACK – Waiting for an acknowledgment of the connection termination
request previously sent to the remote TCP (which includes an
acknowledgment of its connection termination request).
•
TIME-WAIT – Waiting for enough time to pass to be sure the remote TCP
received the acknowledgment of its connection termination request.
•
CLOSED – There is no connection state.
Local host The IP address of the MSDP router interface with the peer.
Local port The TCP port the MSDP router is using for the BGP4 TCP session with the
neighbor.
Remote host The IP address of the neighbor.
Remote port The TCP port number of the peer end of the connection.
ISentSeq The initial send sequence number for the session.
SendNext The next sequence number to be sent.
TotUnAck The number of sequence numbers sent by the MSDP router that have not been
acknowledged by the neighbor.
SendWnd The size of the send window.
TotSent The number of sequence numbers sent to the neighbor.
ReTrans The number of sequence numbers that the MSDP router retransmitted
because they were not acknowledged.
IRcvSeq The initial receive sequence number for the session.
RcvNext The next sequence number expected from the neighbor.
RcvWnd The size of the receive window.
TotalRcv The number of sequence numbers received from the neighbor.
TABLE 130 MSDP peer information (Continued)
This field... Displays...
