Trunk group overview
Trunk group rules
lists the maximum number of trunk groups you can configure on a device and the valid
number of ports in a trunk group. The table applies to static and LACP trunk ports.
•
You cannot configure a port as a member of a trunk group if 802.3ad link aggregation is
enabled on the port.
•
Unlike other devices, trunk groups on devices listed in
are not classified as switch
trunk groups or server trunk groups.
•
Port assignment on a module need not be consecutive. The port range can contain gaps. For
example, you can configure ports 1, 3, and 4 (excluding 2). Refer to
•
Port assignment on a module need not be consecutive. The port range can contain gaps. For
example, you can configure ports 1, 3, and 4 (excluding 2). Refer to
•
You can select any port to be the primary port of the trunk group.
•
You cannot combine Gbps and 10-Gbps ports in the same trunk group.
TABLE 60
Trunk group support
Model
Maximum number of Gbps
trunk groups
Valid number of ports in a group
TurboIron X Series
28
2, 3, 4, 5, 6, 7, or 8
424F
42XG
Lnk
Act
Lnk
Act
1
2
424C
424C
424C
424C
424F
424C
8X-12GM-4
Console
Pwr
Lnk
Odd
Even
SYS
EJECT
DC OK
ALM
AC OK
DC OK
ALM
AC OK
SYS
EJECT
DC OK
ALM
AC OK
SYS
EJECT
DC OK
ALM
AC OK
SYS
EJECT
Odd
Even
Lnk
Lnk
424C
424F
Odd
Even
Odd
Even
Lnk
