Brocade TurboIron 24X Series Configuration Guide User Manual
Page 1084

1050
Brocade TurboIron 24X Series Configuration Guide
53-1003053-01
Viewing DSCP-based QoS settings
Syntax: show qos-tos
This command shows the following information.
TABLE 175
DSCP-based QoS configuration information
This field...
Displays...
DSCP-priority map
d1 and d2
The DSCP to forwarding priority mappings that are currently in effect.
NOTE: The example above shows the default mappings. If you change the
mappings, the command displays the changed mappings
Traffic class -> 802.1 priority map
Traffic Class and 802.1p
Priority
The traffic class to 802.1p Priority mappings that are currently in effect.
NOTE: The example above shows the default mappings. If you change the
mappings, the command displays the changed mappings.
TurboIron#show qos-tos
DSCP-->Traffic-Class map: (DSCP = d1d2: 00, 01...63)
d2| 0 1 2 3 4 5 6 7 8 9
d1 |
-----+----------------------------------------
0 | 0 0 0 0 0 0 0 0 1 1
1 | 1 1 1 1 1 1 2 2 2 2
2 | 2 2 2 2 3 3 3 3 3 3
3 | 3 3 4 4 4 4 4 4 4 4
4 | 5 5 5 5 5 5 5 5 6 6
5 | 6 6 6 6 6 6 7 7 7 7
6 | 7 7 7 7
Traffic-Class-->802.1p-Priority map (use to derive DSCP--802.1p-Priority):
Traffic | 802.1p
Class | Priority
--------+---------
0 | 0
1 | 1
2 | 2
3 | 3
4 | 4
5 | 5
6 | 6
7 | 7
--------+---------
