Brocade TurboIron 24X Series Configuration Guide
505
53-1003053-01
Displaying IP configuration information and statistics
ICMP statistics
The ICMP statistics are derived from RFC 792, “Internet Control Message Protocol”, RFC 950, “Internet Standard
Subnetting Procedure”, and RFC 1256, “ICMP Router Discovery Messages”. Statistics are organized into Sent and
Received. The field descriptions below apply to each.
total
The total number of ICMP messages sent or received by the device.
errors
This information is used by Brocade customer support.
unreachable
The number of Destination Unreachable messages sent or received by the device.
time exceed
The number of Time Exceeded messages sent or received by the device.
parameter
The number of Parameter Problem messages sent or received by the device.
source quench
The number of Source Quench messages sent or received by the device.
redirect
The number of Redirect messages sent or received by the device.
echo
The number of Echo messages sent or received by the device.
echo reply
The number of Echo Reply messages sent or received by the device.
timestamp
The number of Timestamp messages sent or received by the device.
timestamp
reply
The number of Timestamp Reply messages sent or received by the device.
addr mask
The number of Address Mask Request messages sent or received by the device.
addr mask
reply
The number of Address Mask Replies messages sent or received by the device.
irdp
advertisement
The number of ICMP Router Discovery Protocol (IRDP) Advertisement messages sent or received
by the device.
irdp solicitation The number of IRDP Solicitation messages sent or received by the device.
UDP statistics
received
The number of UDP packets received by the device.
sent
The number of UDP packets sent by the device.
no port
The number of UDP packets dropped because they did not have a valid UDP port number.
input errors
This information is used by Brocade customer support.
TCP statistics
The TCP statistics are derived from RFC 793, “Transmission Control Protocol”.
active opens
The number of TCP connections opened by sending a TCP SYN to another device.
passive opens
The number of TCP connections opened by this device in response to connection requests (TCP
SYNs) received from other devices.
failed attempts
This information is used by Brocade customer support.
active resets
The number of TCP connections this device reset by sending a TCP RESET message to the device
at the other end of the connection.
passive resets
The number of TCP connections this device reset because the device at the other end of the
connection sent a TCP RESET message.
input errors
This information is used by Brocade customer support.
in segments
The number of TCP segments received by the device.
TABLE 81
CLI display of IP traffic statistics – Layer 3 Switch (Continued)
This field...
Displays...
