Multicast Source Discovery Protocol (MSDP)
Displaying peer information
To display summary MSDP peer information, use the following CLI method.
Syntax: show ip msdp peer
TABLE 129 MSDP summary information
This field... Displays...
Peer Address The IP address of the peer interface with the Layer 3 Switch
State The state of the MSDP router connection with the peer. The state can be one
of the following:
•
CONNECT – The session is in the active open state.
•
ESTABLISH – The MSDP session is fully up.
•
IDLE– The session is idle or inactive.
•
LISTEN – The session is in the passive open state.
KA In The number of MSDP Keepalive messages the MSDP router has received from
the peer
KA Out The number of MSDP Keepalive messages the MSDP router has sent to the
peer
SA In The number of Source Active messages the MSDP router has received from the
peer
SA Out The number of Source Active messages the MSDP router has sent to the peer
NOT In The number of Notification messages the MSDP router has received from the
peer
NOT Out The number of Notification messages the MSDP router has sent to the peer
TurboIron(config-msdp-router)#show ip msdp peer
Total number of MSDP Peers: 2
IP Address State
1 10.251.17.30 ESTABLISHED
Keep Alive Time Hold Time
60 90
Message Sent Message Received
Keep Alive 2 3
Notifications 0 0
Source-Active 0 640
Last Connection Reset Reason:Reason Unknown
Notification Message Error Code Received:Unspecified
Notification Message Error SubCode Received:Not Applicable
Notification Message Error Code Transmitted:Unspecified
Notification Message Error SubCode Transmitted:Not Applicable
TCP Connection state: ESTABLISHED
Local host: 10.251.17.29, Local Port: 8270
Remote host: 10.251.17.30, Remote Port: 639
ISentSeq: 16927 SendNext: 685654 TotUnAck: 0
SendWnd: 16384 TotSent: 668727 ReTrans: 1
IRcvSeq: 45252428 RcvNext: 45252438 RcvWnd: 16384
TotalRcv: 10 RcvQue: 0 SendQue: 0
