Displaying IP configuration information and statistics
Displaying IP traffic statistics
To display IP traffic statistics on a Layer 2 Switch, enter the following command at any CLI level.
Syntax: show ip traffic
The show ip traffic command displays the following information.
TABLE 83 CLI display of ARP cache
This field... Displays...
IP The IP address of the device.
Mac The MAC address of the device.
NOTE: If the MAC address is all zeros, the entry is for the default gateway, but the Layer 2
Switch does not have a link to the gateway.
Port The port on which the entry was learned.
Age The number of minutes the entry has remained unused. If this value reaches the ARP aging
period, the entry is removed from the cache.
VlanId The VLAN the port that learned the entry is in.
NOTE: If the MAC address is all zeros, this field shows a random VLAN ID, since the Layer 2
Switch does not yet know which port the device for this entry is attached to.
Total ARP Entries The number of entries in the ARP cache.
TurboIron#show ip traffic
IP Statistics
27 received, 24 sent
0 fragmented, 0 reassembled, 0 bad header
0 no route, 0 unknown proto, 0 no buffer, 0 other errors
ICMP Statistics
Received:
0 total, 0 errors, 0 unreachable, 0 time exceed
0 parameter, 0 source quench, 0 redirect, 0 echo,
0 echo reply, 0 timestamp, 0 timestamp rely, 0 addr mask
0 addr mask reply, 0 irdp advertisement, 0 irdp solicitation
Sent:
0 total, 0 errors, 0 unreachable, 0 time exceed
0 parameter, 0 source quench, 0 redirect, 0 echo,
0 echo reply, 0 timestamp, 0 timestamp rely, 0 addr mask
0 addr mask reply, 0 irdp advertisement, 0 irdp solicitation
UDP Statistics
0 received, 0 sent, 0 no port, 0 input errors
TCP Statistics
1 current active tcbs, 4 tcbs allocated, 0 tcbs freed 0 tcbs protected
0 active opens, 0 passive opens, 0 failed attempts
0 active resets, 0 passive resets, 0 input errors
27 in segments, 24 out segments, 0 retransmission
