PIM Sparse
Syntax: show ip pim resource
The number of Hardware (Hw) resources available are 2048.
For each software data structure listed in the output, the following information is shown.
TABLE 120 Output of show ip pim resource command
This field... Displays...
alloc Number of nodes of that data that are currently allocated in memory.
in-use Number of allocated nodes in use
avail Number of allocated nodes are not in use
get-fail Number of allocated notes that failed
limit Maximum number of nodes that can be allocated for a data structure. This may or may not be
configurable, depending on the data structure
get-mem Number of attempts made to use allocated nodes
TurboIron#show ip pim resource
alloc in-use avail get-fail limit get-mem size init
NBR list 64 0 64 0 512 0 20 64
timer 256 0 256 0 8192 0 27 256
pimsm J/P elem 0 0 0 0 48960 0 9 1530
pimsm group2rp 0 0 0 0 16384 0 10 64
pimsm L2 reg xmt 64 0 64 0 14848 0 20 64
mcache 256 0 256 0 1024 0 161 256
mcache hash link 997 0 997 0 231304 0 8 997
mcache 2nd hash 9 0 9 0 997 0 124 9
graft if no mcache 197 0 197 0 45704 0 10 197
pim/dvm global group 256 0 256 0 59392 0 8 256
pim/dvmrp prune 128 0 128 0 40960 0 24 128
Output intf-vlan 2000 0 2000 0 464000 0 14 2000
group hash link 97 0 97 0 22504 0 8 97
2D vlan for nbr, glb 2000 0 2000 0 464000 0 14 2000
Output intf. 1024 0 1024 0 237568 0 20 1024
2D for glb grp 1024 0 1024 0 237568 0 12 1024
pim/dvm config. intf 128 15 113 0 29696 15 8 128
Prune rate limit 256 0 256 0 59392 0 24 256
Distributed add cpu 128 0 128 0 29696 0 12 128
L2 VIDX 256 0 256 0 4096 0 10 256
L2 VIDX hash 997 0 997 0 231304 0 8 997
igmp group 0 0 0 0 4096 0 16 256
igmp phy port 0 0 0 0 200000 0 22 1024
igmp exist phy port 256 26 230 0 1589248 26 29 256
igmp G/GS query 0 0 0 0 29696 0 12 128
igmp v3 source 0 0 0 0 500000 0 10 2000
igmp v3 tracking 0 0 0 0 118784 0 10 512
igmp glb sorted list 0 0 0 0 500000 0 8 2000
total pool memory 183078 bytes
#of PIM ports: physical 1, VEs 6 (max: 512), loopback 1, tunnels 0 (GRE 0, PIM/
DVMRP 0)
Available VIDX: 4004, Blackhole VIDX: 0
Total Mlls in pool: 2048(Hw),4096(Sw) Allocated MLL: 0(Hw),0(Sw) Available MLL
: 2048(Hw),4096(Sw)
SW processed pkts 0
