PIM Sparse
Displaying a list of multicast groups
To display a list of the IP multicast groups the Layer 3 Switch is forwarding, enter the following
command at any CLI level.
TurboIron#show ip pim group
Total number of groups: 1
Index 1 Group 228.1.0.88
Group member at e2: v33 EX 0,
Group member at e13: v55 EX 0,
Group member at e1: v5 EX 0,
Syntax: show ip pim group
Bootstrap Msg
interval
How frequently the BSR configured on the Layer 3 Switch sends the RP set to the RPs
within the PIM Sparse domain. The RP set is a list of candidate RPs and their group
prefixes. A candidate RP group prefix indicates the range of PIM Sparse group numbers
for which it can be an RP.
NOTE: This field contains a value only if an interface on the Layer 3 Switch is elected to
be the BSR. Otherwise, the field is blank.
Candidate-RP
Advertisement
interval
How frequently the candidate PR configured on the Layer 3 Switch sends candidate RP
advertisement messages to the BSR.
NOTE: This field contains a value only if an interface on the Layer 3 Switch is configured
as a candidate RP. Otherwise, the field is blank.
Join/Prune interval
How frequently the Layer 3 Switch sends PIM Sparse Join/Prune messages for the
multicast groups it is forwarding. This field show the number of seconds between
Join/Prune messages.
The Layer 3 Switch sends Join/Prune messages on behalf of multicast receivers who
want to join or leave a PIM Sparse group. When forwarding packets from PIM Sparse
sources, the Layer 3 Switch sends the packets only on the interfaces on which it has
received join requests in Join/Prune messages for the source group.
You can change the Join/Prune interval if needed. Refer to
SPT Threshold
The number of packets the Layer 3 Switch sends using the path through the RP before
switching to using the SPT path.
PIM Sparse interface information
NOTE: You also can display IP multicast interface information using the show ip pim interface command.
However, this command lists all IP multicast interfaces, including regular PIM (dense mode). The show ip
pim sparse command lists only the PIM Sparse interfaces.
Interface
The type of interface and the interface number. The interface type can be one of the
following:
•
Ethernet
•
VE
The number is either a port number or the virtual interface (VE) number.
TTL Threshold
Following the TTL threshold value, the interface state is listed. The interface state can be
one of the following:
•
Disabled
•
Enabled
Local Address
Indicates the IP address configured on the port or virtual interface.
TABLE 117
Output of show ip pim sparse (Continued)
This field...
Displays...
