Configuring extended numbered ACLs
Extended numbered ACL syntax
Syntax: [no] access-list deny | permit |
[/] |
[| ] [
/] [dscp-marking <0-63> [802.1p-priority-marking <0 –7...>
]] [dscp-matching <0-63>] [log] [precedence | <0 – 7>] [tos <0– 63> | ]
[traffic policy ]
Syntax: [no] access-list deny | permit host any any
Syntax: [no] ip access-group in
The parameter is the extended access list number. Specify a number from 100 – 199.
The deny | permit parameter indicates whether packets that match the policy are dropped or
forwarded.
The parameter indicates the type of IP packet you are filtering. You can specify a
well-known name for any protocol whose number is less than 255. For other protocols, you must
enter the number. Enter “?” instead of a protocol to list the well-known names recognized by the
CLI.
The | parameter specifies the source IP host for the policy. If you want
the policy to match on all source addresses, enter any.
The parameter specifies the portion of the source IP host address to match against.
The is in dotted-decimal notation (IP address format). It is a four-part value, where
each part is 8 bits (one byte) separated by dots, and each bit is a one or a zero. Each part is a
number ranging from 0 to 255, for example 0.0.0.255. Zeros in the mask mean the packet source
address must match the . Ones mean any value matches. For example, the
and values 10.157.22.26 0.0.0.255 mean that all hosts in the Class C
subnet 10.157.22.x match the policy.
If you prefer to specify the wildcard (mask value) in Classless Interdomain Routing (CIDR) format,
you can enter a forward slash after the IP address, then enter the number of significant bits in the
mask. For example, you can enter the CIDR equivalent of “10.157.22.26 0.0.0.255” as
“10.157.22.26/24”. The CLI automatically converts the CIDR number into the appropriate ACL
mask (where zeros instead of ones are the significant bits) and changes the non-significant portion
of the IP address into zeros. For example, if you specify 10.157.22.26/24 or 10.157.22.26
0.0.0.255, then save the changes to the startup-config file, the value appears as 10.157.22.0/24
(if you have enabled display of subnet lengths) or 10.157.22.0 0.0.0.255 in the startup-config file.
If you enable the software to display IP subnet masks in CIDR format, the mask is saved in the file
in “/” format. To enable the software to display the CIDR masks, enter the ip
show-subnet-length command at the global CONFIG level of the CLI. You can use the CIDR format
to configure the ACL entry regardless of whether the software is configured to display the masks in
CIDR format.
NOTE
If you use the CIDR format, the ACL entries appear in this format in the running-config and
startup-config files, but are shown with subnet mask in the display produced by the show ip
access-list command.
The | parameter specifies the destination IP host for the policy. If
you want the policy to match on all destination addresses, enter any.
