Page 307: Chapter 15
Brocade TurboIron 24X Series Configuration Guide
273
53-1003053-01
Chapter
15
Configuring Metro Features
In this chapter
•
•
•
Virtual Switch Redundancy Protocol (VSRP) . . . . . . . . . . . . . . . . . . . . . . . . 298
Topology groups
A topology group is a named set of VLANs that share a Layer 2 topology. Topology groups simplify
configuration and enhance scalability of Layer 2 protocols by allowing you to run a single instance
of a Layer 2 protocol on multiple VLANs.
You can use topology groups with the following Layer 2 protocols:
•
STP
•
MRP
•
VSRP
•
802.1W
Topology groups simplify Layer 2 configuration and provide scalability by enabling you to use the
same instance of a Layer 2 protocol for multiple VLANs. For example, if a device is deployed in a
Metro network and provides forwarding for two MRP rings that each contain 128 VLANs, you can
configure a topology group for each ring. If a link failure in a ring causes a topology change, the
change is applied to all the VLANs in the ring topology group. Without topology groups, you would
need to configure a separate ring for each VLAN.
NOTE
If you plan to use a configuration saved under an earlier software release and the configuration
contains STP groups, the CLI converts the STP groups into topology groups when you save the
configuration. For backward compatibility, you can still use the STP group commands. However, the
CLI converts the commands into the topology group syntax. Likewise, the show stp-group command
displays STP topology groups.
Master VLAN and member VLANs
Each topology group contains a master VLAN and can contain one or more member VLANs and
VLAN groups:
•
Master VLAN – The master VLAN contains the configuration information for the Layer 2
protocol. For example, if you plan to use the topology group for MRP, the topology group master
VLAN contains the ring configuration information.
