PIM Sparse
This display shows the following information.
Displaying BSR information
To display BSR information, enter the following command at any CLI level.
This example show information displayed on a Layer 3 Switch that has been elected as the BSR.
The following example shows information displayed on a Layer 3 Switch that is not the BSR. Notice
that some fields shown in the example above do not appear in the example below.
TurboIron#show ip pim bsr
PIMv2 Bootstrap information
local BSR address = 10.95.7.1
local BSR priority = 5
Syntax: show ip pim bsr
This display shows the following information.
TABLE 118 Output of show ip pim group
This field... Displays...
Total number of Groups Lists the total number of IP multicast groups the Layer 3 Switch is forwarding.
NOTE: This list can include groups that are not PIM Sparse groups. If interfaces on
the Layer 3 Switch are configured for regular PIM (dense mode), these
groups are listed too.
Index The index number of the table entry in the display.
Group The multicast group address
Group member
Ports The Layer 3 Switch ports connected to the receivers of the groups.
TABLE 119 Output of show ip pim bsr
This field... Displays...
BSR address
or
local BSR address The IP address of the interface configured as the PIM Sparse Bootstrap Router (BSR).
NOTE: If the word “local” does not appear in the field, this Layer 3 Switch is the BSR. If the
word “local” does appear, this Layer 3 Switch is not the BSR.
Uptime The amount of time the BSR has been running.
NOTE: This field appears only if this Layer 3 Switch is the BSR.
TurboIron#show ip pim bsr
PIMv2 Bootstrap information
This system is the elected Bootstrap Router (BSR)
BSR address: 10.95.7.1
Uptime: 00:33:52, BSR priority: 5, Hash mask length: 32
Next bootstrap message in 00:00:20
Next Candidate-RP-advertisement in 00:00:10
RP: 10.95.7.1
group prefixes:
224.0.0.0 / 4
Candidate-RP-advertisement period: 60
