666
Brocade TurboIron 24X Series Configuration Guide
53-1003053-01
BGP4 parameters
NOTE
To disable BGP4 without losing the BGP4 configuration information, remove the local AS (for
example, by entering the no local-as
configuration information but is not operational until you set the local AS again.
BGP4 parameters
You can modify or set the following BGP4 parameters:
•
Optional – Define the router ID. (The same router ID also is used by OSPF.)
•
Required – Specify the local AS number.
•
Optional – Add a loopback interface for use with neighbors.
•
Required – Identify BGP4 neighbors.
•
Optional – Change the Keep Alive Time and Hold Time.
•
Optional – Change the update timer for route changes.
•
Optional – Enable fast external fallover.
•
Optional – Specify a list of individual networks in the local AS to be advertised to remote ASs
using BGP4.
•
Optional – Change the default local preference for routes.
•
Optional – Enable the default route (default-information-originate).
•
Optional – Enable use of a default route to resolve a BGP4 next-hop route.
•
Optional – Change the default MED (metric).
•
Optional – Enable next-hop recursion.
•
Optional – Change the default administrative distances for EBGP, IBGP, and locally originated
routes.
•
Optional – Require the first AS in an Update from an EBGP neighbor to be the neighbor AS.
•
Optional – Change MED comparison parameters.
•
Optional – Disable comparison of the AS-Path length.
•
Optional – Enable comparison of the router ID.
•
Optional – Enable auto summary to summarize routes at an IP class boundary (A, B, or C).
•
Optional – Aggregate routes in the BGP4 route table into CIDR blocks.
•
Optional – Configure the router as a BGP4 router reflector.
•
Optional – Configure the Layer 3 Switch as a member of a BGP4 confederation.
•
Optional – Change the default metric for routes that BGP4 redistributes into RIP or OSPF.
•
Optional – Change the parameters for RIP, OSPF, or static routes redistributed into BGP4.
•
Optional – Change the number of paths for BGP4 load sharing.
•
Optional – Change other load-sharing parameters
•
Optional – Define BGP4 address filters.
•
Optional – Define BGP4 AS-path filters.
•
Optional – Define BGP4 community filters.
•
Optional – Define IP prefix lists.
