802.1s Multiple Spanning Tree Protocol

Displaying MSTP information for a specified instance

The following example displays MSTP information specified for an MSTP instance.

Refer to

Table 94

for details about the display parameters.

Displaying MSTP information for CIST instance 0

Instance 0 is the Common and Internal Spanning Tree Instance (CIST). When you display
information for this instance there are some differences with displaying other instances. The
following example displays MSTP information for CIST Instance 0.

To display details about the MSTP configuration, enter the following command.

State

The port current spanning tree state. A port can have one of the
following states:

Forwarding

Discarding

Learning

Disabled

Designated Cost

Port path cost to the root bridge.

Max Hop cnt

The maximum hop count configured for this instance.

Root Hop cnt

Hop count from the root bridge.

TABLE 94

Output from Show MSTP (Continued)

This field...

Displays...

TurboIron#show mstp 1

MSTP Instance 1 - VLANs: 2

----------------------------------------------------------------------------

Bridge Max RegionalRoot IntPath Designated Root Root

Identifier Hop Bridge Cost Bridge Port Hop

hex cnt hex hex cnt

800100000080af01 20 800100000080af01 0 800100000080af01 Root 20

Port Pri PortPath Role State Designa- Designated

Num Cost ted cost bridge

1 128 2000 MASTER FORWARDING 0 800100000080af01

TurboIron#show mstp 0

MSTP Instance 0 (CIST) - VLANs: 1

----------------------------------------------------------------------------

Bridge Bridge Bridge Bridge Bridge Root Root Root Root

Identifier MaxAge Hello FwdDly Hop MaxAge Hello FwdDly Hop

hex sec sec sec cnt sec sec sec cnt

800000000080af01 20 2 15 20 20 2 15 19

Root ExtPath RegionalRoot IntPath Designated Root

Bridge Cost Bridge Cost Bridge Port

hex hex hex

8000000000bb9876 2000 800000000080af01 0 8000000000bb9876 1

Port Pri PortPath P2P Edge Role State Designa- Designated

Num Cost Mac Port ted cost bridge

1 128 2000 T F ROOT FORWARDING 0 8000000000bb9876
