Brocade Unified IP MIB Reference (Supporting FastIron Releases 07.5.00 and 08.0.10) - Manual (Page 741)

Unified IP MIB Reference 715
53-1003106-01
Proprietary traps
67
Traps for BFD
The following Bidirectional Forwarding Detection (BFD) traps are supported only on the Brocade
NetIron MLX, Brocade MLXe, Brocade NetIron XMR, Brocade NetIron CES, and Brocade NetIron
CER series devices.
Trap name and
number Varbinds Severity Description and trap message
mplsXCUp
1.3.6.1.2.1.1
0.166.2.0.1 mplsXCOperStatus Notification Generates when the mplsXCOperStatus object for one entry
in mplsXCTable are about to enter the up(1) state from
down(2) state.
The included values of the mplsXCOperStatus object must be
set equal to the new up(1) state. The two instances of the
mplsXCOperStatus object in the notification indicate the
range of indexes that are affected.
Sample syslog message:
MPLS: The LSP XC with id , in segment
id and out segment id has come up
mplsXCDown
1.3.6.1.2.1.1
0.166.2.0.2 mplsXCOperStatus Notification Generates when the mplsXCOperStatus object for one entry
in mplsXCTable are about to enter the down(2) state from
up(1) state.
The included values of the mplsXCOperStatus object must be
set equal to the down(2) state. The two instances of the
mplsXCOperStatus object in the notification indicate the
range of indexes that are affected.
Sample syslog message:
MPLS: The LSP XC with id , in segment
id and out segment id has went
down
