Unified IP MIB Reference 459
53-1003106-01
Port configuration tables
46
Port configuration tables
The following table define the size, encapsulation format, and cost of the packet that will be
transmitted through a port.
IP interface port configuration table
NOTE
The following table is not supported on the Brocade MLXe, Brocade NetIron MLX, Brocade NetIron
XMR, Brocade NetIron CES, and Brocade NetIron CER series devices.
snRtIpPortAccessFilters
brcdIp.1.2.2.7.1.3
Syntax: OCTET STRING Read-write Each octet represents a filter number.
snRtIpPortAccessRowSt
atus
brcdIp.1.2.2.7.1.4
Syntax: Integer Read-write Controls the management of the table rows. The following values can be
written:
•
delete(3) – Delete the row.
•
create(4) – Create a new row.
•
modify(5) – Modify an existing row.
If the row exists, then a SET with a value of create(4) returns a "bad
value" error. Deleted rows are removed from the table immediately.
The following values can be returned on reads:
•
noSuch(0) – No such row.
•
invalid(1) – Row is inoperative.
•
valid(2) – Row exists and is valid.
Name, OID, and syntax Access Description
Name, OID, and syntax Access Description
snRtIpPortConfigTable
brcdIp.1.2.2.8 None The IP port configuration table.
snRtIpPortConfigPortInd
ex
brcdIp.1.2.2.8.1.1
Syntax: PortIndex Read-only An index for an entry in the IP port configuration table.
For FastIron or NetIron products, the value of this object is from 1
through 42.
snRtIpPortMtu
brcdIp.1.2.2.8.1.2
Syntax: Integer Read-write Indicates the maximum size of IP packets that will be transmitted on the
port.
snRtIpPortEncap
brcdIp.1.2.2.8.1.3
Syntax: Integer Read-write Shows the encapsulation format that will be used on the IP frame
transmitted on the port:
•
ethernet(1) – Ethernet
•
snap(2) – ATM and Ethernet
•
hdlc(3) – POS
•
ppp(4) – POS
