608 Unified IP MIB Reference
53-1003106-01
VPLS endpoint2 table
61
VPLS endpoint2 table
The following table supports VPLS ISID mapping that is configured in the inner VLAN at the
endpoint level. It contains objects for the VPLS endpoints that are not available in the pseudo Wire
or draft-ietf-pwe3-pw-mib-11.txt MIB. The VPLS endpoint table replaces fdryVplsEndPointTable.
fdryVllEndPointVlanTagMode
brcdIp.1.2.15.2.1.1.1.2
Syntax: Integer32 Read-only Indicates the VLAN mode of this endpoint. Ports can have only
the following modes:
•
tagged(1)
•
untagged(2)
fdryVllEndPointClassOfService
brcdIp.1.2.15.2.1.1.1.3
Syntax: Unsigned32 Read-only For VLL, this value is used to select the appropriate tunnel whose
CoS value is the same as, or almost approaching this value.
For VLL-local, this value is applied to the inbound traffic of an
endpoint.
Valid values: 0 - 7
fdryVllEndPointInHCPkts
brcdIp.1.2.15.2.1.1.1.4
Syntax: Counter64 Read-only This object indicates the number of packets ingressing into this
endpoint. This is available in the output for show mpls statistics
vll.
fdryVllEndPointOutHCPkts
brcdIp.1.2.15.2.1.1.1.5
Syntax: Counter64 Read-only This object indicates the number of ingress packets from this
endpoint as shown in the show mpls statistics vll-local output.
For VLL-local, this value is the fdryVllEndPointInHCPkts of the
other endpoint.
fdryVllEndPointAdminStatus
brcdIp.1.2.15.2.1.1.1.6
Syntax: Integer32 Read-only The desired administrative status of the endpoint.
•
up(1)
•
down(2)
fdryVllEndPointOperStatus
brcdIp.1.2.15.2.1.1.1.7
Syntax: PwOperStatusTC Read-only Indicates the operational status of the endpoint:
•
up(1)
•
down(2)
fdryVllEndPointRowStatus
brcdIp.1.2.15.2.1.1.1.8
Syntax: RowStatus Read-only Status will be active(1) if the endpoint is up; otherwise it will be
not in service.
Name, OID, and syntax Access Description
Name, OID, and syntax Access Description
fdryVplsEndPoint2Table
brcdIp.1.2.15.2.2.3 None This table specifies information about the VPLS endpoints that
are not available in the PW MIB or the VPLS draft MIB. This
table replaces fdryVplsEndPointTable, as inner VLAN or ISID
has been added as an index of this table.
fdryVplsEndPoint2VlanId
brcdIp.1.2.15.2.2.3.1.1
Syntax: PwVlanCfg None This value specifies the VLAN ID value of this endpoint.
fdryVplsEndPoint2InnerTagType
brcdIp.1.2.15.2.2.3.1.2
Syntax: Integer None This value indicates the inner ID for the endpoint:
•
invalid(1)
•
innerVlan(2)
•
isid(3)
If no inner tag is specified, the value invalid(1) is returned.
