Brocade Unified IP MIB Reference (Supporting FastIron Releases 07.5.00 and 08.0.10) - Manual (Page 122)

96 Unified IP MIB Reference
53-1003106-01
LLDP-EXT-DOT3-MIB
2
LLDP-EXT-DOT3-MIB
The following tables in the LLDP-EXT-DOT3-MIB are supported on the Brocade NetIron XMR,
Brocade NetIron MLX, Brocade MLXe, Brocade NetIron CES, and Brocade NetIron CER series
devices.
• lldpXdot3PortConfigTable
• lldpXdot3LocPortTable
• lldpXdot3LocPowerTable
• lldpXdot3LocLinkAggTable
• lldpXdot3LocMaxFrameSizeTable
• lldpXdot3RemPortTable
• lldpXdot3RemPowerTable
• lldpXdot3RemLinkAggTable
• lldpXdot3RemMaxFrameSizeTable
lldpXdot3PortConfigTable
The following table lists the objects that controls the selection of LLDP TLVs to be transmitted on
the individual ports.
lldpXdot3LocPortTable
The following table contains one row per port of Ethernet port information (as part of the LLDP
802.3 organizational extension) on the local system known to the agent.
Object Object identifier Supported?
lldpXdot1RemProtocolIndex 1.0.8802.1.1.2.1.5.32962.1.3.4.
1.1
Yes
lldpXdot1RemProtocolId 1.0.8802.1.1.2.1.5.32962.1.3.4.
1.2
Yes
Object Object identifier Supported?
lldpXdot3PortConfigTLVsTxEnable 1.0.8802.1.1.2.1.5.4623.1.1.1.1.1 Yes
Object Object identifier Supported?
lldpXdot3LocPortAutoNegSupported 1.0.8802.1.1.2.1.5.4623.1.2.1.1.1 Yes
lldpXdot3LocPortAutoNegEnabled 1.0.8802.1.1.2.1.5.4623.1.2.1.1.2 Yes
lldpXdot3LocPortAutoNegAdvertisedCap 1.0.8802.1.1.2.1.5.4623.1.2.1.1.3 Yes
lldpXdot3LocPortOperMauType 1.0.8802.1.1.2.1.5.4623.1.2.1.1.4 Yes
