IP RIP port configuration table
52
IP RIP port configuration table
The IP RIP port configuration table contains the configuration of RIP on a particular interface.
Before you can use this table, RIP must be enabled in the device and must be configured with
permit and deny commands.
NOTE
The IP RIP MIBs are not supported on the Brocade MLXe, Brocade NetIron MLX, Brocade NetIron
XMR, Brocade NetIron CES, Brocade NetIron CER series, and Brocade FastIron devices.
IP RIP redistribution table
The IP RIP redistribution table contains routes where RIP routes are redistributed. RIP can
redistribute routes from other routing protocols such as OSPF and BGP4 into RIP. A redistributed
route means that a Layer 3 Switch learns through another protocol, and then distributes into RIP.
Name, OID, and syntax Access Description
snRtIpRipPortConfigTable
brcdIp.1.2.3.2 None The IP RIP port configuration table.
snRtIpRipPortConfigPortIndex
brcdIp.1.2.3.2.1.1
Syntax: PortIndex Read-only The port index for an entry in the IP RIP port configuration table.
snRtIpRipPortVersion
brcdIp.1.2.3.2.1.2
Syntax: Integer Read-write Specifies the IP RIP version on this port:
•
disabled(0) – RIP is disabled on this port.
•
v1Only(1) – RIP version 1 only.
•
v2Only(2) – RIP version 2 only.
•
v1CompatibleV2(3) – RIP version 2 is compatible with
version 1.
snRtIpRipPortPoisonReverse
brcdIp.1.2.3.2.1.3
Syntax: Integer Read-write Indicates if poison reverse is enabled:
•
disabled(0)
•
enabled(1)
Poison reverse prevents routing loops and slow convergence
within the network.
snRtIpRipPortLearnDefault
brcdIp.1.2.3.2.1.4
Syntax: Integer Read-write Indicates if the ability to learn advertised routes is enabled on
the interface:
•
disabled(0)
•
enabled(1)
Name, OID, and syntax Access Description
snRtIpRipRedisTable
brcdIp.1.2.3.3 None The IP RIP redistribution table.
snRtIpRipRedisIndex
brcdIp.1.2.3.3.1.1
Syntax: Integer Read-only The table index for a IP RIP redistribution entry. There can be up to 64
entries in this table.
