22

Unified IP MIB Reference

53-1003106-01

RFC 2863: The Interfaces Group MIB

2

Preserved SNMP statistics on interfaces

SNMP statistics in the ifTable and ifXTable for physical interfaces on Brocade MLXe and NetIron
devices are preserved when the snmp-server preserve-statistics command is configured. After
configuring snmp-server preserve-statistics, the SNMP statistics listed in the following tables are
separated from the CLI statistics. When the clear statistics interface-type interface-id command is
entered on the CLI, the command clears only CLI statistics, leaving the SNMP statistics intact.

IF-MIB (RFC 2863) ifTable objects

Statistics from the following objects in the ifTable are preserved when the snmp-server
preserve-statistics command is enabled on the CLI.

ifTable objects

Syntax

ifIndex
1.3.6.1.2.1.2.2.1.1

InterfaceIndex

ifDescr
1.3.6.1.2.1.2.2.1.2

DsiplayString

ifType
1.3.6.1.2.1.2.2.1.3

IANAifType

ifMtu
1.3.6.1.2.1.2.2.1.4

Integer32

ifSpeed
1.3.6.1.2.1.2.2.1.5

Gauge32

ifAdminStatus
1.3.6.1.2.1.2.2.1.7

PhysAddress

ifOperStatus
1.3.6.1.2.1.2.2.1.8

Integer

ifInOctets
1.3.6.1.2.1.2.2.1.10

Counter32

ifInUcastPkts
1.3.6.1.2.1.2.2.1.11

Counter32

ifInNUcastPkts
1.3.6.1.2.1.2.2.1.12
NOTE: This object is deprecated in the

8x10 modules installed on the
Brocade MLXe, Brocade NetIron
XMR, Brocade NetIron MLX devices
and also on the Brocade FastIron
devices.

Counter32

ifInDiscards
1.3.6.1.2.1.2.2.1.13

Counter32

ifInErrors
1.3.6.1.2.1.2.2.1.14

Counter32

ifInUnknownProtos
1.3.6.1.2.1.2.2.1.15

Counter32
