Agent stacking board table
5
Agent stacking board table
The following table provides information on boards in a stacking device.
snAgentBrdMediaLedString
brcdIp.1.1.2.2.1.1.19
Syntax: OCTET STRING
NOTE: This object is not
supported on the
Brocade MLXe, Brocade
NetIron MLX, Brocade
NetIron XMR, Brocade
NetIron CES, and
Brocade NetIron CER
series devices.
Read-only Applies to devices with an LED for media type. It contains an octet
string with 64-bits per slot. The value of each bit can be one of the
following:
•
0 – Half-duplex
•
1 – Full-duplex
snAgentBrdSpeedLedString
brcdIp.1.1.2.2.1.1.20
Syntax: OCTET STRING Read-only Applies to devices that have an LED for traffic speed. Contains an
octet string with 64-bits per slot. The value of each bit can be one
of the following:
•
0 – 10 Mbit
•
1 – 100 Mbit
snAgentBrdAlarmLedString
brcdIp.1.1.2.2.1.1.21
Syntax: OCTET STRING Read-only Applies to devices that have an alarm LED. Contains an octet string
with 64-bits per slot. The value of each bit can be one of the
following:
•
0 – No alarm
•
1 – Alarm
snAgentBrdTxTrafficLedString
brcdIp.1.1.2.2.1.1.22
Syntax: OCTET STRING Read-only Applies only to POS modules. Contains an octet string with 64-bits
per slot. The value of each bit can be one of the following:
•
0 – No transmit traffic
•
1 – Transmit traffic
snAgentBrdRxTrafficLedString
brcdIp.1.1.2.2.1.1.23
Syntax: OCTET STRING Read-only Applies only to POS modules. Contains an octet string with 64-bits
per slot. The value of each bit can be one of the following:
•
0 – No receive traffic
•
1 – Receive traffic
snAgentBrdMemoryTotal
brcdIp.1.1.2.2.1.1.24
Syntax: CounterBasedGauge64 Read-only Shows the total memory in bytes within this module.
snAgentBrdMemoryAvailable
brcdIp.1.1.2.2.1.1.25
Syntax: CounterBasedGauge64 Read-only Shows the available total memory in bytes within this module.
snAgentBrdMemoryUtil100thPe
rcent
brcdIp.1.1.2.2.1.1.28
Syntax: Unsigned32 Read-only Indicates the dynamic memory that is currently utilized within this
module, in units of one-hundredth of a percent.
snAgentBrdUpTime
brcdIp.1.1.2.2.1.1.29
Syntax: TimeTicks Read-only Indicates the uptime for the module, in units of one-hundredth of a
second.
This value is valid only if the value of snAgentBrdModuleStatus is
“moduleRunning(10)”.
Name, OID, and syntax Access Description
