BGP4 neighbor filter group table
49
BGP4 neighbor filter group table
The BGP4 neighbor filter group table controls the routes that the device learns or advertises.
Name, OID, and syntax Access Description
snBgp4NeighFilterGroupTable
brcdIp.1.2.11.8.1 None The BGP4 neighbor filter group table.
snBgp4NeighFilterGroupNeighIp
brcdIp.1.2.11.8.1.1.1
Syntax: IpAddress Read-only Shows the IP address for a neighbor entry.
snBgp4NeighFilterGroupDir
brcdIp.1.2.11.8.1.1.2
Syntax: Integer Read-only Shows the direction of advertisements to which the access
list is applied:
•
out(0) – Outgoing
•
in(1) – Incoming
snBgp4NeighFilterGroupAccessList
brcdIp.1.2.11.8.1.1.3
Syntax: OCTET STRING Read-write Identifies the access list that is being used to filter a
neighbor group.
This is a number from 1 through 0xFFFF. The incoming and
outgoing list can have a mximum of 16 entries each. This
integer is represented by two octets.
snBgp4NeighFilterGroupRowStatus
brcdIp.1.2.11.8.1.1.4
Syntax: IpAddress Read-write Controls the management of the table rows. The following
values can be written:
•
delete(3) – Deletes the row.
•
create(4) – Creates a new row.
•
modify(5) – Modifies an existing row.
If the row exists, then a SET with a value of create(4)
returns a "bad value" error. Deleted rows are removed from
the table immediately.
The following values can be returned on reads:
•
noSuch(0) – No such row.
•
invalid(1) – Row is inoperative.
•
valid(2) – Row exists and is valid.
snBgp4NeighFilterGroupInFilterList
brcdIp.1.2.11.8.1.1.5
Syntax: OCTET STRING Read-write Identifies the filter list that is being used to filter incoming
routes from a neighbor group.
This is a number from 1 through 0xFFFF. The incoming and
outgoing list can have a mximum of 16 entries each. This
integer is represented by two octets.
snBgp4NeighFilterGroupOutFilterList
brcdIp.1.2.11.8.1.1.6
Syntax: OCTET STRING Read-write Identifies the filter list that is being used to filter outgoing
routes from a neighbor group.
This is a number from 1 through 0xFFFF. The incoming and
outgoing list can have a mximum of 16 entries each. This
integer is represented by two octets.
snBgp4NeighFilterGroupInAsPathAc
cessList
brcdIp.1.2.11.8.1.1.7
Syntax: OCTET STRING Read-write Identifies the AS-Path list that is being used to filter
incoming routes from a neighbor group.
This is a number from 1 through 0xFFFF. The incoming and
outgoing list can have a mximum of 16 entries each. This
integer is represented by two octets.
snBgp4NeighFilterGroupOutAsPathA
ccessList
brcdIp.1.2.11.8.1.1.8
Syntax: OCTET STRING Read-write Identifies the AS-Path list that is being used to filter
outgoing routes from a neighbor group.
This is a number from 1 through 0xFFFF. The incoming and
outgoing list can have a mximum of 16 entries each. This
integer is represented by two octets.
