Unified IP MIB Reference 461
53-1003106-01
Port configuration tables
46
IP interface configuration table
The following MIB objects are supported on the Brocade NetIron devices.
Name, OID, and syntax Access Description
snRtIpPortIfAccessTable
brcdIp.1.2.2.19 None IP port if access table.
snRtIpPortIfAccessInterf
aceIndex
brcdIp.1.2.2.19.1.1
Syntax: InterfaceIndex Read-only The interface index for port access entry.
snRtIpPortIfAccessDirec
tion
brcdIp.1.2.2.19.1.2
Syntax: Integer Read-only The incoming or outgoing check.
snRtIpPortIfAccessFilter
s
brcdIp.1.2.2.19.1.3
Syntax: OCTET STRING Read-write The first octet correspond to the first filter number and so on.
snRtIpPortIfAccessRowS
tatus
brcdIp.1.2.2.19.1.4
Syntax: RowStatus Read-write To create or delete a port access entry.
Name, OID, and syntax Access Description
snRtIpPortIfConfigTable
brcdIp.1.2.2.20 None IP port if configuration table.
snRtIpPortIfConfigInterf
aceIndex
brcdIp.1.2.2.20.1.1
Syntax: InterfaceIndex Read-only The if index for port configuration entry.
snRtIpPortIfMtu
brcdIp.1.2.2.20.1.2
Syntax: Integer32 Read-Write The maximun transfer unit:
•
Ethernet MTU range: 46 to 1500
•
POS MTU range: 60 to 4470
•
ATM MTU range: 1500 to 9180
•
ATM SubIf MTU range: 1500 to 9180
For jumbo support, the MTU range could be higher.
snRtIpPortIfEncap
brcdIp.1.2.2.20.1.3
Syntax: Integer Read-Write Data link encapsulation to be used on the IP frame transmitted on the
port.
snRtIpPortIfMetric
brcdIp.1.2.2.20.1.4
Syntax: Integer Read-Write The metric for port configuration entry.
