Unified IP MIB Reference 591
53-1003106-01
Pseudo wire MIB
60
Values that affect some VLL services
The following table shows how the value of pwType for VLL services is determined.
The following table shows how the value of pwEnetPwVlan for VLL services is determined.
pwEnetVlanMode brcdIp.3.1.4.1.1.1.
3
•
portBased(1) -
No VLAN tag
•
noChange(2) -
Retain same
VLAN ID
•
changeVlan(3)-
Change id
•
addVlan(4)
•
removeVlan(5)
•
portBased(1) - no
VLAN tag; both
instances use
default VLAN ID
•
noChange(2) -
retain same
VLAN ID
•
changeVlan(3) -
change
non-default VLAN
IDs between two
instances
•
addVlan(4) -
instance ID 1 has
default VLAN,
Instance ID 2 has
non-default VLAN
•
removeVlan(5) -
instance ID 1 has
default VLAN,
Instance ID 2 has
non-default VLAN
•
portBased(1) -
no vlan tag
pwEnetPortVlan brcdIp.3.1.4.1.1.1.
4 Endpoint VLAN ID,
which can be 4096
or an actual VLAN ID. Endpoint VLAN ID Always 0. For
end-point, use
fdryVplsEndPointTa
ble.
pwEnetPortIfIndex brcdIp.3.1.4.1.1.1.
5 Endpoint ifIndex Endpoint ifIndex Always 0. For
endpoint, use
fdryVplsEndPointTa
ble.
pwEnetPwIfIndex brcdIp.3.1.4.1.1.1.
6 Tunnel ifIndex Because no tunnel,
value 0 Tunnel ifIndex
pwEnetRowStatus brcdIp.3.1.4.1.1.1.
7 Always active(1) Always active(1) Always active(1)
pwEnetStorageType brcdIp.3.1.4.1.1.1.
8 Always
permanent(4) Always permanent(4) Always
permanent(4)
Pseudo Wire tag mode is End Point tag mode is Value of pwType is
raw (untagged) untagged ethernet(5)
raw (untagged) tagged ethernet(5)
tagged untagged ethernetTagged(4)
tagged tagged ethernetTagged(4)
Object Object identifier Support for VLL Support for VLL-local Support for VPLS
