Unified IP MIB Reference 429
53-1003106-01
VRRP and VRRP-E virtual router configuration table
42
snVrrpVirRtr2TransToBa
ckupStateCnts
brcdIp.1.2.12.5.1.1.23
Syntax: Counter32 Read-only Shows the number of times this interface has changed from the
master state to the backup state.
snVrrpVirRtr2CurrDeadI
nt
brcdIp.1.2.12.5.1.1.24
Syntax: Integer32 Read-only Shows the current dead interval in increments of 100 milliseconds for
the virtual router. This is the time period that a backup waits for a hello
message from the master before determining that the master is no
longer active. If the master does not send a hello message before the
dead interval expires, the backups negotiate (compare priorities) to
select a new master for the VRID.
snVrrpVirRtr2TrackPortL
ist
brcdIp.1.2.12.5.1.1.25
Syntax: OCTET STRING Read-write Specifies the router’s physical track port membership. The
membership includes physical ports and virtual ports whose state is to
be monitored.
Each port index is an ifIndex. If there are four or more consecutive
ifIndexes, then the encoding and decoding scheme is range-based, as
follows:
•
Each range prefix with 0000 (2 octets) is not a valid ifIndex.
•
The first two octets in a set of four octets indicate the beginning of
the range. The next two octets show the end of the range.
•
IfIndexes that are not in a range are displayed as they are.
For example, you may see the following lists:
•
Port list: 0001..0005 0015 0032..0047
0001..0005 and 0032..0047 show ranges of ifindexes; whereas,
0015 is one ifindex
•
Port list in PDU: 0000 0001 0005 000f 0000 0020 002f
The list contains ifindexes not in a range.
If this object is configured, then the preference level of this interface
will be adjusted dynamically depending on the state of the track port.
The interface's preference level is reduced by the value of preference
level parameter when the track port states first changes from up to
down. When the track port returns to the up state, the interface's
preference level is increased by the amount specified by the
preference level.
snVrrpVirRtr2AdvertiseB
ackup
brcdIp.1.2.12.5.1.1.26
Syntax: Integer Read-write Indicates if the ability for this backup to advertise itself to the current
master is enabled:
•
disabled(0)
•
enabled(1)
Default: disabled(0}
snVrrpVirRtr2MasterIpA
ddr
brcdIp.1.2.12.5.1.1.27
Syntax: IpAddress Read-only Shows the master’s real or virtual (primary) IP address. This IP address
is listed as the source in VRRP and VRRP-E advertisement that was
last received by this virtual router.
snVrrpVirRtr2IpAddrCou
nt
brcdIp.1.2.12.5.1.1.28
Syntax: Integer Read-only Shows the number of IP addresses that are associated with this virtual
router. This number is equal to the number of rows in the
vrrpAssoIpAddrTable of the standard MIB that corresponds to a given
ifindex and VRID pair.
snVrrpVirRtr2VirtualMac
Addr
brcdIp.1.2.12.5.1.1.29
Syntax: MAC address Read-only Shows the virtual MAC address of the virtual router.
Name, OID, and syntax Access Description
