ACL accounting table
40
ACL accounting table
The following table contains the ACLs configured on the NetIron devices.
NOTE
The ACL accounting table is supported on the Brocade NetIron XMR, Brocade NetIron MLX, Brocade
MLXe, Brocade NetIron CES, and Brocade NetIron CER series devices. SNMP-WALK on the
agAclAccntEntry object may not return the full output in certain configurations of Brocade NetIron
devices.
snAgAclIfBindName
brcdIp.1.2.2.15.4.1.4
Syntax: DisplayString Read-create The name of the IPv4 ACL name bound to the Interface.
Maximum 255 characters are allowed.
snAgAclIfBindVifPortList
brcdIp.1.2.2.15.4.1.5
Syntax: Octet string Read-create Contains a list of ports for binding a virtual interface. Each
port index is an ifIndex. If there are four or more
consecutive ifIndexes, then they will be encoded. THe
Encoding and decoding scheme is range-based.
Each range prefix with 0000 (2 octets) where 0000 is not
a valid ifIndex. The next 2 octets indicates the lower range
ifIndex, followed by 2 octets of higher range ifIndex. The
individual (non- range) ones will be displayed as is.
For example:
Port list: 0001..0005 0015 0032..0047
Port list in PDU: 0000 0001 0005 000f 0000 0020 002f
snAgAclIfRowStatus
brcdIp.1.2.2.15.4.1.6
Syntax: SnRowStatus Read-create Controls the management of the table rows. The following
values can be written:
•
delete(3) – Delete the row.
•
create(4) – Create a new row.
•
modify(5) – Modify an existing row.
If the row exists, then a SET with a value of create(4)
returns a "bad value" error. Deleted rows are removed
from the table immediately.
The following values can be returned on reads:
•
noSuch(0) – No such row.
•
invalid(1) – Row is inoperative.
•
valid(2) – Row exists and is valid.
snAgAclIfBindDenyLogging
brcdIp.1.2.2.15.4.1.7
Syntax: Integer Read-create Enables or disables deny logging.
snAgAclIfIpv6BindName
brcdIp.1.2.2.15.4.1.8
Syntax: DisplayString Read-create The name of the IPv6 ACL name bound to the interface.
A maximum 200 characters is allowed.
Name, OID, and syntax Access Description
