Unified IP MIB Reference 397
53-1003106-01
Chapter
40
IPv4 ACL MIB Definition
In this chapter
• ACL global MIB objects . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 397
• IPv4 ACL table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 398
• ACL bind to port table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 405
• ACL accounting table. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 406
• Textual conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 408
• Layer 2 ACL next clause table. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 409
• Layer 2 ACL configuration table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 410
• Layer 2 ACL binding configuration table . . . . . . . . . . . . . . . . . . . . . . . . . . . 412
• PBR ACL Accounting Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 413
ACL global MIB objects
The following table lists the global MIB objects of the ACL table.
Name, OID, and syntax Access Description
snAgAclGblAcctEnable
brcdIp.1.2.2.15.1.2
Syntax: Integer
NOTE: This object is not
supported on the Brocade
NetIron CES and Brocade
NetIron CER series
devices.
Read-write Specifies the administration status of the ACL accounting.
•
disabled(0)
•
enabled(1)
snAgAclGblIfIPv4AcctClear
brcdIp.1.2.2.15.1.3
Syntax: InterfaceIndexOrZero
NOTE: This object is not
supported on the Brocade
NetIron CES and Brocade
NetIron CER series
devices.
Read-write Clears the IPv4 ACL accounting information of a particular
interface. The value “0” clears IPv4 ACL accounting
information on all the interfaces. Returns the value 0 for
SNMP GET and GET-NEXT requests.
