System stacking temperature table
11
System stacking temperature table
The following table shows temperature information for a module’s temperature sensor in the
stacking devices.
Software licensing
The following table contains information about the software licenses configured on the device.
snAgentTempThresholdLe
vel
brcdIp.1.1.2.13.2.1.2
Syntax: Integer None The temperature threshold level of the module for which threshold
levels represented by this row are applicable.
snAgentTempThresholdHi
ghValue
brcdIp.1.1.2.13.2.1.3
Syntax: Integer Read-write The high value for the temperature threshold, above which the fans
would need to operate at the next higher speed. If the value reaches
more than the high threshold value for the 'high' level, the module will
be shut down.
snAgentTempThresholdLo
wValue
brcdIp.1.1.2.13.2.1.4
Syntax: Integer Read-write The low value for the temperature threshold, below which the fans
would need to operate at the next lower speed. This value is not
applicable for the 'low' level, as there are no more lower speeds.
Name, OID, and syntax Access Description
Name, OID, and syntax Access Description
snAgentTemp2Table
brcdIp.1.1.2.13.3 None This table lists the temperatures of the modules in each unit. This
table is applicable only to modules with temperature sensors.
snAgentTemp2UnitNum
brcdIp.1.1.2.13.3.1.1
Syntax: Integer None The unit number of the module that contains the temperature
sensor represented by this row.
snAgentTemp2SlotNum
brcdIp.1.1.2.13.3.1.2
Syntax: Integer None The slot number of the module that contains the temperature sensor
represented by this row.
snAgentTemp2SensorId
brcdIp.1.1.2.13.3.1.3
Syntax: Integer None The temperature sensor ID of the member module that is
represented by this row:
For Brocade FastIron devices:
•
sensor# 1 - Intake Side Temperature
•
sensor# 2 - Exhaust Side Temperature
snAgentTemp2SensorDescr
brcdIp.1.1.2.13.3.1.4
Syntax: DisplayString Read-only Description of the temperature sensor. This is the same as
snAgentTempSensorId, which is in numeric format. It is used to
traverse the temperature sensor table. The description provides the
meaning and purpose of this sensor.
There can be up to 128 characters in the description.
snAgentTemp2Value
brcdIp.1.1.2.13.3.1.5
Syntax: Integer Read-only Temperature of the sensor represented by this row. Each unit is 0.5º
Celsius.
Valid values: 110º - 250º Celsius.
