FDP cache table
19
Name, OID, and syntax Access Description
snFdpCacheTable
brcdIp.1.1.3.20.1.2.1 None The FDP cache table.
snFdpCacheIfIndex
brcdIp.1.1.3.20.1.2.1.1.1 None Shows the ifIndex value of the local interface.
snFdpCacheDeviceIndex
brcdIp.1.1.3.20.1.2.1.1.2
Syntax: Integer32 Read-only A unique value for each device from which FDP or CDP messages are
being received.
snFdpCacheDeviceId
brcdIp.1.1.3.20.1.2.1.1.3
Syntax: DisplayString Read-only Shows a description for the device as reported in the most recent FDP
or CDP message.
A zero-length string indicates no Device-ID field (TLV) was reported in
the most recent FDP or CDP message.
snFdpCacheAddressType
brcdIp.1.1.3.20.1.2.1.1.4
Syntax: Integer Read-only Indicates the type of address contained in the “snFdpCacheAddress”
object for this entry:
•
ip(1)
•
ipx(2)
•
appletalk(3)
snFdpCacheAddress
brcdIp.1.1.3.20.1.2.1.1.5
Syntax: OCTET STRING Read-only Shows the network-layer address of the device's SNMP agent, as
reported in the most recent FDP or CDP message. A device may have
more than one address. This object shows the first address on the
device.
The format of this object depends on the value of the
snFdpCacheAddressType object:
•
ip(1) – 4 octets
•
ipx(2) – 10 octets:
-
Octets 1-4 – Network number
-
Octets 5-10 – Host number
•
appletalk(3) – 3 octets:
-
Octets 1-2 – Network number
-
Octet 3 – Host number
snFdpCacheVersion
brcdIp.1.1.3.20.1.2.1.1.6
Syntax: DisplayString Read-only Shows the software version running in the device as reported in the
most recent FDP or CDP message.
snFdpCacheDevicePort
brcdIp.1.1.3.20.1.2.1.1.7
Syntax: DisplayString Read-only Shows the port ID of the device as reported in the most recent FDP or
CDP message. This will typically be the value of the ifName object.
A zero-length string indicates no Port-ID field (TLV) was reported in the
most recent FDP or CDP message.
snFdpCachePlatform
brcdIp.1.1.3.20.1.2.1.1.8
Syntax: DisplayString Read-only Shows the device's hardware platform as reported in the most recent
FDP or CDP message.
A zero-length string indicates that no Platform field (TLV) was reported
in the most recent FDP or CDP message.
snFdpCacheCapabilities
brcdIp.1.1.3.20.1.2.1.1.9
Syntax: DisplayString Read-only Shows the device's functional capabilities as reported in the most
recent FDP or CDP message.
snFdpCacheVendorId
brcdIp.1.1.3.20.1.2.1.1.10
Syntax: Integer Read-only Indicates if FDP or CDP received the entry:
•
fdp(1)
•
cdp(2)
