Layer 2 ACL configuration table
40
Layer 2 ACL configuration table
The following objects are available for Layer 2 ACL configuration.
NOTE
The following fdryL2AclTable has support only for the numbered Layer2 ACL and does not have
support for the named Layer2 ACL.
Name, OID, and syntax Access Description
fdryL2AclNextClauseTable
brcdIp.1.2.2.15.6 None This read-only table contains the list of the next lowest available
clause index that can be used for creating a new entry in
fdryL2AclTable. The clause index values will not change as a result
of switchovers or hitless upgrades, but may change as a result of a
device reload. However, the relative order of persistent entries
would remain the same.
fdryL2AclNextClauseIndex
brcdIp.1.2.2.15.6.1.1
Syntax:
“fdryClauseIndexTC”
Read-only The next lowest available clause index for a given Layer 2 ACL
number. The maximum value of this object is the configured
maximum number of clauses for a Layer 2 ACL.
Even though the syntax of fdryL2AclClauseIndex is
“fdryClauseIndexTC” , its value will be from 1 to the configured
maximum clause entries for each Layer 2 ACL.
Name, OID, and syntax Access Description
fdryL2AclTable
brcdIp.1.2.2.15.7 None The table of Layer 2 ACLs. A Layer 2 ACL number can have 64
(default) to 256 clauses. The clause index values will not change
as a result of switchovers or hitless upgrades, but may change
as a result of a device reload. However, the relative order of
persistent entries remains the same.
fdryL2AclNumber
brcdIp.1.2.2.15.7.1.1
Syntax: AclNumber None The access list number for this entry. For Layer 2 ACLs, valid
values are from 400 through 599.
fdryL2AclClauseIndex
brcdIp.1.2.2.15.7.1.2
Syntax:
“fdryClauseIndexTC”
None The index of the clause within a given ACL number. During row
creation, the clause index value should match the next available
clause index for a given ACL number. It is advisable to first
perform a Get operation on fdryL2AclNextClauseTable for a given
ACL number, and use the value of fdryL2AclNextClauseIndex
returned by the agent.
fdryL2AclAction
brcdIp.1.2.2.15.7.1.3
Syntax: Action Read-write Action to take if the Layer 2 packet on the port matches this ACL.
fdryL2AclSourceMac
brcdIp.1.2.2.15.7.1.4
Syntax: MAC address Read-write Optional source MAC address. By default, it matches with any
source MAC address within a packet.
Default: ‘000000000000'H
