BGP4 aggregate address table
49
BGP4 aggregate address table
By default, the Layer 3 Switch advertises individual routes for all the networks. The aggregation
feature allows you to configure the Layer 3 Switch to aggregate routes in a range of networks into a
single Classless Inter-Domain Routing (CIDR) number.
snBgp4AddrFilterSourceMask
brcdIp.1.2.11.2.1.1.4
Syntax: IpAddress Read-write Specifies the source IP subnet mask.
snBgp4AddrFilterDestIp
brcdIp.1.2.11.2.1.1.5
Syntax: IpAddress Read-write Specifies the destination IP address.
snBgp4AddrFilterDestMask
brcdIp.1.2.11.2.1.1.6
Syntax: IpAddress Read-write Specifies the destination IP subnet mask.
snBgp4AddrFilterRowStatus
brcdIp.1.2.11.2.1.1.7
Syntax: Integer Read-write Controls the management of the table rows. The following
values can be written:
•
delete(3) – Deletes the row.
•
create(4) – Creates a new row.
•
modify(5) – Modifies an existing row.
If the row exists, then a SET with a value of create(4) returns a
"bad value" error. Deleted rows are removed from the table
immediately.
The following values can be returned on reads:
•
noSuch(0) – No such row.
•
invalid(1) – Row is inoperative.
•
valid(2) – Row exists and is valid.
Name, OID, and syntax Access Description
Name, OID, and syntax Access Description
snBgp4AggregateAddrTable
brcdIp.1.2.11.3.1 None The BGP4 aggregate address table.
snBgp4AggregateAddrIp
brcdIp.1.2.11.3.1.1.1
Syntax: IpAddress Read-only Shows the aggregate address IP address.
Specify 0 for the host portion and for the network portion that
differs among the networks in the aggregate. For example, to
aggregate 10.0.1.0, 10.0.2.0, and 10.0.3.0, enter the IP
address 10.0.0.0 and the network mask 255.255.0.0 in the
next object.
snBgp4AggregateAddrMask
brcdIp.1.2.11.3.1.1.2
Syntax: IpAddress Read-only Shows the aggregate address IP subnet mask.
