220 Unified IP MIB Reference
53-1003106-01
CAM statistics table
10
• L3 4096 - 32767 (0x01000 - 0x07fff), free 28662 (0x06ff6)
Values are shared across the DMA. Also, if IP activity across DMAs is not different, some fields may
show the same values.
CAM statistics table
The following table shows CAM statistics for all master DMAs. The objects are equivalent to the dm
cam stat dma master num command.
NOTE
The following table is not supported on the Brocade MLXe, Brocade NetIron MLX, Brocade NetIron
XMR, Brocade NetIron CES, and Brocade NetIron CER series devices.
Name, OID, and syntax Access Description
snCAMStatTable
brcdIp.1.1.2.12.3 None CAM statistics table.
snCamStatDMAIdNumber
brcdIp.1.1.2.12.3.1.1
Syntax: Unsigned32 Read-only DMA ID number.
snCamStatDMAMasterNumber
brcdIp.1.1.2.12.3.1.2
Syntax: Unsigned32 Read-only DMA master for the DMA ID number.
snCamStatFreePool0Entries
brcdIp.1.1.2.12.3.1.3
Syntax: Unsigned32 Read-only CAM free pool0 entries.
snCamStatFreePool1Entries
brcdIp.1.1.2.12.3.1.4
Syntax: Unsigned32 Read-only CAM free pool1 entries.
snCamStatFreePool2Entries
brcdIp.1.1.2.12.3.1.5
Syntax: Unsigned32 Read-only CAM free pool2 entries.
snCamStatFreePool3Entries
brcdIp.1.1.2.12.3.1.6
Syntax: Unsigned32 Read-only CAM free pool3 entries.
snCamStatFreeL2Entries
brcdIp.1.1.2.12.3.1.7
Syntax: Unsigned32 Read-only CAM free Layer 2 entries
snCamStatFreeL2LowestSection
brcdIp.1.1.2.12.3.1.8
Syntax: Unsigned32 Read-only CAM free Layer 2 lowest section entries.
snCamStatHostLookupCount
brcdIp.1.1.2.12.3.1.9
Syntax: Unsigned32 Read-only CAM host lookup count for router.
snCamStatRouteLookupCount
brcdIp.1.1.2.12.3.1.10
Syntax: Unsigned32 Read-only CAM route lookup count for router.
