12

Unified IP MIB Reference

53-1003106-01

RFC 2096: IP Forwarding Table MIB

2

RFC 2096: IP Forwarding Table MIB

RFC 2096 is supported on the following devices:

On FastIron devices, RFC 2096 replaces RFC 1213.

On NetIron devices, RFC 2096 is obsoleted by RFC 4292 and it supports both IPv4 and IPv6
forwarding tables.

RFC 2233: The Interfaces Group MIB using SMIv2

The interface entry table or ifXTable is based on RFC 2233. It contains information about the
interfaces. Each sub-layer is considered to be an interface. This table contains entries for the ATM
physical ports, as well as for any sub-interfaces that have been configured.

Object group name

Object identifier

ipCidrRouteDest

1.3.6.1.2.1.4.24.4.1.1

ipCidrRouteMask

1.3.6.1.2.1.4.24.4.1.2

ipCidrRouteTos

1.3.6.1.2.1.4.24.4.1.3

ipCidrRouteNextHop

1.3.6.1.2.1.4.24.4.1.4

ipCidrRouteIfIndex

1.3.6.1.2.1.4.24.4.1.5

ipCidrRouteType

1.3.6.1.2.1.4.24.4.1.6

ipCidrRouteProto

1.3.6.1.2.1.4.24.4.1.7

ipCidrRouteAge

1.3.6.1.2.1.4.24.4.1.8

ipCidrRouteInfo

1.3.6.1.2.1.4.24.4.1.9

ipCidrRouteNextHopAS

1.3.6.1.2.1.4.24.4.1.10

ipCidrRouteMetric1

1.3.6.1.2.1.4.24.4.1.11

ipCidrRouteMetric2

1.3.6.1.2.1.4.24.4.1.12

ipCidrRouteMetric3

1.3.6.1.2.1.4.24.4.1.13

ipCidrRouteMetric4

1.3.6.1.2.1.4.24.4.1.14

ipCidrRouteMetric5

1.3.6.1.2.1.4.24.4.1.15

ipCidrRouteStatus

1.3.6.1.2.1.4.24.4.1.16

Object group name

Object identifier

ifMIB

1.3.6.1.2.1.31

ifMIBObjects

1.3.6.1.2.1.31.1

ifTable

1.3.6.1.2.1.2.2

ifXtable

1.3.6.1.2.1.31.1.1

ifStackTable

1.3.6.1.2.1.31.1.2
