92
Unified IP MIB Reference
53-1003106-01
LLDP-MIB
2
lldpRemManAddrTable
The following table contains one or more rows per-management address information on the remote
system learned on a particular port contained in the local chassis known to the agent.
lldpRemUnknownTLVTable
The following table contains information about an incoming TLV that is not recognized by the
receiving LLDP agent.
lldpRemOrgDefInfoTable
The following table contains one or more rows per physical network connection that advertises the
organizationally-defined information.
lldpRemChassisId 1.0.8802.1.1.2.1.4.1.1.5
Yes
lldpRemPortIdSubtype 1.0.8802.1.1.2.1.4.1.1.6
Yes
lldpRemPortId 1.0.8802.1.1.2.1.4.1.1.7
Yes
lldpRemPortDesc 1.0.8802.1.1.2.1.4.1.1.8
Yes
lldpRemSysName 1.0.8802.1.1.2.1.4.1.1.9
Yes
lldpRemSysDesc 1.0.8802.1.1.2.1.4.1.1.10
Yes
lldpRemSysCapSupported 1.0.8802.1.1.2.1.4.1.1.11
Yes
lldpRemSysCapEnabled 1.0.8802.1.1.2.1.4.1.1.12
Yes
Object
Object identifier
Supported?
lldpRemManAddrSubtype 1.0.8802.1.1.2.1.4.2.1.1
Yes
lldpRemManAddr 1.0.8802.1.1.2.1.4.2.1.2
Yes
lldpRemManAddrIfSubtype 1.0.8802.1.1.2.1.4.2.1.3
Yes
lldpRemManAddrIfId 1.0.8802.1.1.2.1.4.2.1.4
Yes
lldpRemManAddrOID 1.0.8802.1.1.2.1.4.2.1.5
Yes
Object
Object identifier
Supported?
lldpRemUnknownTLVType
1.0.8802.1.1.2.1.4.3.1.1
Yes
lldpRemUnknownTLVInfo
1.0.8802.1.1.2.1.4.3.1.2
Yes
Object
Object identifier
Supported?
lldpRemOrgDefInfoOUI 1.0.8802.1.1.2.1.4.4.1.1
Yes
lldpRemOrgDefInfoSubtype 1.0.8802.1.1.2.1.4.4.1.2
Yes
lldpRemOrgDefInfoIndex 1.0.8802.1.1.2.1.4.4.1.3
Yes
lldpRemOrgDefInfo 1.0.8802.1.1.2.1.4.4.1.4
Yes
Object
Object identifier
Supported?
