192 Unified IP MIB Reference
53-1003106-01
Fabric drop count statistics table
7
Fabric drop count statistics table
The Brocade NetIron MLX, Brocade MLXe, and Brocade NetIron XMR devices are provided with
Simple Network Management Protocol (SNMP) Management Information Base (MIB) support for
the fabric drop count. The fabric drop counters are maintained by the system and are updated
automatically whenever there is a packet drop at switch fabric level.
The brcdFabricStatsTable contains information of Switch Fabric Module (SFM) related information
specific to the Brocade NetIron MLX, Brocade MLXe, and Brocade NetIron XMR devices.
NOTE
The following brcdFabricStatsTable is supported only on the High-speed SFM (HSFM) cards. The
table support GET and GET-NEXT requests.
snSwQosMechanism
brcdIp.1.1.3.1.40
Syntax: Integer
NOTE: This object is not
supported on the
Brocade MLXe,
Brocade NetIron
MLX, Brocade
NetIron XMR,
Brocade NetIron
CES, and Brocade
NetIron CER series
devices.
Read-write Specifies the Quality of Service (QoS) mechanism:
•
strict(0)
•
weighted(1)
Default: weighted(1)
snSwSingleStpMode
brcdIp.1.1.3.1.41
Syntax: Integer Read-write Indicates if the Single Spanning Tree System Mode in the Switch
Group is enabled:
•
disabled(0)
•
enabled(1)
Default: disabled(0)
snSwFastStpMode
brcdIp.1.1.3.1.42
Syntax: Integer Read-write Indicates if Fast Spanning Tree System Mode in the Switch Group is
enabled:
•
disabled(0)
•
enabled(1)
snSwViolatorIfIndex
brcdIp.1.1.3.1.43
Syntax: Integer32 Read-only The port number of the device that received a violator packet. This
number is included in the locked address violator trap.
snSwSingleStpVLanId
brcdIp.1.1.3.1.44
Syntax: Integer32 Read-only The VLAN ID of the Single Spanning Tree VLAN if Single Spanning Tree
was enabled. This object returns zero if Single Spanning Tree was
disabled.
Name, OID, and syntax Access Description
