Sierra M6‐4 SAS/SATA Protocol Analyzer User Manual 45
Easy Mode (Pre‐Defined Setups) LeCroy Corporation
SAS vs. SATA: SATA Dialog does not show “Exclude RRDY” or “Exclude NOTIFY”.
SATA Dialog replaces “Exclude SATA_CONT” with “Exclude CONT” and
“Exclude SATA_SYNC” with “Exclude SYNC”.
Project Tree
The Project Tree on the right side of the main window displays a comprehensive tree
structured overview of the project. The project tree shows what to capture, on what the
analyzer triggers, and the capture memory settings.
Capture Tab Fields
The Capture tab has the following fields:
Exclude SATA_CONT (SAS) or Exclude CONT (SATA)
Check this to exclude SATA_CONT primitives from the data capture.
Exclude SATA_SYNC (SAS) or Exclude SYNC (SATA)
Check this to exclude SATA_SYNC primitives from the data capture.
Exclude OOB Signals
Check this to exclude OOB signals from the data capture.
Exclude XXXX
Check this to exclude XXXX patterns from the data capture.
Exclude Payload except
Check this to exclude Payload of Data Frames from the data capture. You can except a
number of DWORD(s). 
Note: The Data Report does not reflect excluded Payload of Data Frames.
Note: When showing truncated data in the Data Payload View, the truncation points are marked with
a separator placed between payloads. You can get more information about the data exclusion
using the tooltip over the separator.
Exclude ALIGN
Check this to exclude ALIGN primitives from the data capture.
