Run hardware – Teledyne LeCroy STX M6-1 SAS_SATA Protocol Analyzer User Manual User Manual
Page 163
Sierra M6‐4 SAS/SATA Protocol Analyzer User Manual
161
Performance Analysis
LeCroy Corporation
Run Hardware
To perform the defined analysis, click the
Run Hardware button and wait for the
result to display.
Area Chart
Columns and Bar Chart
Line Chart
Pie Chart
Switch between 2D and 3D
Show/Hide Legend Window
Grid lines On/Off
