Sierra M6‐4 SAS/SATA Protocol Analyzer User Manual 437
Sierra Trainer Generation Language LeCroy Corporation
2. Select Frames, Transactions, SCSI Operations, Management Transactions, ATA
Commands, or OOBs from the top left list box to list that type of event in the Events
Group box.
3. Select one or more events from the Events Group box:
 Packet Types (Header, PHY, Event, Transaction)
 Primitives
 Source Addresses
 Hash Source Addresses
 Destination Addresses
 Hash Destination Addresses
 Data Length
 SMP Frames
 SSP Frames
 Errors
 FIS Types
 FIS Port Number
 Channel
 Data Pattern
 Completion Time
4. Select one of the following options:
 Union: Find all packets matching ANY of the specified events.
 Intersection: Find packets matching ALL of the specified events.
 Exclusion: Exclude packets matching any of the specified events.
Exclusion works with the other two options: 
Select Union AND Exclusion
(=Exclude packets with ANY of the following fields) or 
Intersection AND Exclusion
(=Exclude packets with ALL of the following fields.)
5. Optionally set the search Direction and Origin.
6. Optionally check to Search in Hidden or Find All.
7. Click OK.
After the search finishes, the program displays the packets meeting the search criteria.
