Sierra M6‐4 SAS/SATA Protocol Analyzer User Manual 413
Sierra Trainer Generation Language LeCroy Corporation
WF_REC_RESOURCES_OUTPUT_E Advanced Wait Condition E
This command causes generation to wait for
Event "E" to occur that you defined in the
Generation Options dialog described at the end of
this chapter.
WF_REC_RESOURCES_OUTPUT_F Advanced Wait Condition F
This command causes generation to wait for
Event "F" to occur that you defined in the
Generation Options dialog described at the end of
this chapter.
WF_COMRESET_COMINIT COMRESET OOB Signals
WF_COMSAS COMSAS OOB Signals
WF_COMWAKE COMWAKE OOB Signals
WF_BLOCK1_MISC_RESERVED_0 reserved
WF_BLOCK1_MISC_RESERVED_1 reserved
WF_BLOCK1_MISC_RESERVED_2 reserved
WF_BLOCK1_MISC_RESERVED_3 reserved
WF_BLOCK1_MISC_RESERVED_4 reserved
WF_SATA_CONT primitive
WF_SATA_DMAT primitive
WF_SATA_EOF primitive
WF_SATA_ERROR primitive
WF_SATA_HOLD primitive
WF_SATA_HOLDA primitive
WF_SATA_PMACK primitive
WF_SATA_PMNAK primitive
WF_SATA_PMREQ_P primitive
WF_SATA_PMREQ_S primitive
WF_SATA_R_ERR primitive
WF_SATA_R_IP primitive
WF_SATA_R_OK primitive
WF_SATA_R_RDY primitive
WF_SATA_SOF primitive
WF_SATA_SYNC primitive
WF_SATA_WTRM primitive
WF_SATA_X_RDY primitive
WF_OPEN_ACCEPT primitive
WF_OPEN_REJECT_BAD_DESTINATION primitive
WF_OPEN_REJECT_CONN_RATE_NOT_SUPPO
RTED primitive
WF_OPEN_REJECT_NO_DESTINATION primitive
Wait Command Name Description
