LeCroy Corporation Sierra Trainer Generation Language
406 Sierra M6‐4 SAS/SATA Protocol Analyzer User Manual
SATA Commands
Look at STP sample file for syntax.
 SEND_SATA_FRAME
 SendSATAFrame
 SATAData
 SATA_Data
 SATACRC
 SATA_CRC
 SATAXXXX
 SATA_XXXX
SPEED_NEG_ALIGN1 Generator will go through SPEED_NEG_ALIGN1
stage of SAS SpeedNeg process using current
SPEED_NEG_ALIGN1 settings.
Set Speed = LINK_SPEED_1_5G Generator will change speed to 1.5G (if
MultiSpeed is enabled)
. 
This settings is not applied when
Advanced Connect is set.
Set Speed = LINK_SPEED_3G Generator will change speed to 3G (if
MultiSpeed is enabled).
This settings is not applied when
Advanced Connect is set.
Set Speed = LINK_SPEED_6G Generator will change speed to 6G (if
MultiSpeed is enabled).
This settings is not applied when
Advanced Connect is set.
Send_Phy_Capability Generator will send PHY Capability Bits.
(this command is used in SNW3).
Send_Train_TrainDone Generator will send Train/Train Done Patterns.
(This Command is used in Train Windows).
Delay (#) Generator will wait until # ns before executing
next command.
Power_Expansion_On
Power_Expansion_Off Switch on power expansion card.
Switch off power expansion card
Exit (ExitCode) Call this command in any branch of the Trainer
program to stop execution. After exit, the
Port Status dialog displays the exit code.
Note: The Trainer GUI has LED
indicators:
Green is for pass.
Red is for fail.
No color is for unknown or for
user to review.
