Tools
LeCroy Corporation
Click the Statistics button
at the end of a row to display data report
statistics.
Figure 3.127: SAS: Data Report Statistics
Tools
The Tools are Self Test and Find Device. SATA adds Compliance Test.
Self Test
You can use the built‐in RAM self‐test utility. Select Tools on the main menu bar and
choose Self Test to open the Self Test dialog
Figure 1 SAS: Self Test Command on Tools Menu
Important: Do not run the Self Test using a USB connection. Run the Self Test only on an
Ethernet connection.
