Sierra M6‐4 SAS/SATA Protocol Analyzer User Manual 265
Statistical Report LeCroy Corporation
Click OK. The resulting report are limited to the capture between the defined events.
SAS vs. SATA: SAS adds Transport, SCSI Cmd, SMP Cmd, and Task Mng to the drop‐down
list and deletes FIS and Phy Reset.
Statistical Report Content
SAS: A complete SAS statistical report consists of the following reports, accessed by
clicking the corresponding tab in the dialog:
 General
 Bus Condition
 Primitive
 SSP Transport
 SMP Transport
 STP Transport
 ATA Command
 SCSI Command
 SMP Command
 Task Command
 SAS Address
 Read/Write Command
 Protocol Error
 Performance
 Lanes
 Others
SATA: A complete SATA statistical report consists of the following reports, accessed by
clicking the corresponding tab in the dialog:
 General
 Bus Condition
 Primitive
 FIS
 ATA Command
 ATAPI Command
 Read/Write Command
 Protocol Error
 Performance
 Others
 PM Statistic
 PM Performance
Note: Results are displayed only for items that have been captured in the sample.
