LeCroy Corporation Sierra Trainer Generation Language
412 Sierra M6‐4 SAS/SATA Protocol Analyzer User Manual
WF_DONE_ACK_NAK_TIMEOUT primitive
WF_DONE_CREDIT_TIMEOUT primitive
WF_DONE_NORMAL primitive
WF_DONE_RESERVED_0 primitive
WF_DONE_RESERVED_1 primitive
WF_DONE_RESERVED_TIMEOUT_0 primitive
WF_DONE_RESERVED_TIMEOUT_1 primitive
WF_ERROR primitive
WF_HARD_RESET primitive
WF_AIP_NORMAL primitive
WF_AIP_RESERVED_0 primitive
WF_AIP_RESERVED_1 primitive
WF_AIP_RESERVED_2 primitive
WF_AIP_RESERVED_WAIT_ON_PART primitive
WF_AIP_WAIT_ON_CONN primitive
WF_AIP_WAIT_ON_DEVICE primitive
WF_AIP_WAIT_ON_PARTIAL primitive
WF_IDENTIFY_FRAME Identify Address Frame
WF_OPEN_FRAME Open Address Frame
WF_SMP_REQUEST SMP Request Frame
WF_SMP_RESPONSE SMP Response Frame
WF_REC_RESOURCES_OUTPUT_A Advanced Wait Condition A
This command causes generation to wait for
Event "A" to occur that you defined in the
Generation Options dialog described at the end of
this chapter.
WF_REC_RESOURCES_OUTPUT_B Advanced Wait Condition B
This command causes generation to wait for
Event "B" to occur that you defined in the
Generation Options dialog described at the end of
this chapter.
WF_REC_RESOURCES_OUTPUT_C Advanced Wait Condition C
This command causes generation to wait for
Event "C" to occur that you defined in the
Generation Options dialog described at the end of
this chapter.
WF_REC_RESOURCES_OUTPUT_D Advanced Wait Condition D
This command causes generation to wait for
Event "D" to occur that you defined in the
Generation Options dialog described at the end of
this chapter.
Wait Command Name Description
