Removing expansion cards – Teledyne LeCroy STX M6-1 SAS_SATA Protocol Analyzer User Manual User Manual
Page 34
LeCroy Corporation
Expandability
32
Sierra M6‐4 SAS/SATA Protocol Analyzer User Manual
You can turn the card on or off through the BusEngine by user‐emulation scripts during
Emulation.
Removing Expansion Cards
You can remove expansion cards using two tools:
Standard (flat blade) 3/16” screwdriver
LeCroy Extraction Tool (part number 230‐0160‐00)
